Features:
-
Compact design, fashionable appearance,easy to load paper;
-
Supports multi 1D barcode and QR code printing;
-
Support printer status monitoring function;
-
Support printing queuing ticket function;
-
Support different interface combination;
-
Up to 300mm/s high speed,low noise printing;
-
48 or 80mm adjustable paper separator for option;
-
150KM long life printer head;
-
Supporting wall mounting.
Free Delivery in Windhoek, contact us on info@rockport.com.na for delivery elsewhere, locally and internationally.
|
|
Specification
|
General
|
|
|
Model
|
OCPP-80S
|
|
Name
|
80mm desktop thermal printer with auto cutter
|
|
Color
|
Black
|
|
Interface
|
USB/USB+Lan/USB+BT/ USB+WiFi/URL+WIFI/URL+BT
|
|
Power supply
|
Input：AC 100V-240V,50-60Hz,Output：DC 24V/2.5A
|
|
Cash drawer
|
DC 24V/1A
|
|
Printer head lifespan
|
150KM
|
|
Cutter
|
Auto cutter
|
|
Sensors
|
Paper out, cover open, cutter jam,paper jam and black mark
detection(Optional)
|
|
Accessories
|
Data cable,power adaptor,power cord,paper roller,CD,manual, Paper separator(optional)
|
|
OS supporting
|
Compatible with iOS/ Android/ Windows/Linux
|
|
Safety standards
|
CE ,FCC,Rohs etc
|
|
Printing capability
|
|
|
Printing method
|
Direct thermal line
|
|
Resolution
|
203 DPI
|
|
Printing speed
|
200mm/s (U/UR )
260mm/s (UL/U+BT/ U+WIFI)
300mm/s (URL/ URL+BT/ URL+WIFI)
|
|
Print width
|
72mm
|
|
Graphics printing
|
Supports bitmap download and print ( each bitmap size Max.20K)
|
|
Printing Command
|
Compatible with ESC/POS
|
|
Barcode and character
|
|
|
Barcode
|
1D barcode:
UPC-A/UPC-E/JAN13（EAN13）/JAN8（EAN8）/CODE39/ITF/
CODABAR/CODE93/CODE128
2D barcode：QR CODE（Single USB or UR solution no QR code function）
|
|
Character size
|
ANK character, Font:
A: 12*24dots, 1.5(W)*3.0(H) mm
FontB:9*17dots ,1.1(W)*2.1(H)mm
Simplified/Traditional: 24*24dots, 3.0(W)*3.0(H)mm
|
|
|
Support
|
|
User-defined language
|
PC437/Katakana/PC850/PC860/PC863/PC865/WestEurope/Greek/Hebrew/EastEurope/Iran/WPC1252/PC866/PC852/PC858/IranII/Latvian/Arabic/PT151,1251/PC737/WPC/1257/ThaiVietnam/PC864/PC1001/(Latvian)/(PC1001)/(PT151,1251)/(WPC1257)/(PC864)/(Vietnam)/(Thai)
|
|
Media
|
|
|
Paper type
|
Thermal roll paper
|
|
Paper width
|
48mm/52mm/56mm/64mm/68mm/76mm/80mm (optional)
|
|
Paper Thickness
|
0.06~0.08mm
|
|
Paper roll diameter
|
80mm Max
|
|
Paper separator
|
support
|
|
Physical
|
|
|
Dimension
|
180*142*136mm
|
|
Weight
|
1.65kg
|
|
Package box
|
228*215*165mm
|
|
Environment
|
|
|
Working temperature& humidity
|
0 to 45 degrees centigrade, 10%~80% No condensation
|
|
Storage temperature& humidity
|
-20 to 60 degrees centigrade , 10%~90% No condensation
|
head life 100 KM
Cutter life 1million
Sensors
Paper out, cover open, cutter jam,paper jam and black mark
detection(Optional)
Input AC 100V-240V 50/60HZ
Output DC 24V/2.5A
Working Condition 0°C~45°C, 10%~80%RH
Storage Condition -10°C-60°C,10%~90%RH
Accessories Data cable,power code,paper roller,manual, (standard)
Dimensions 180(D)x142(W)x136(H)mm
Net weight 1.14kg
Gross weight 1.8kg
8 in 1 carton 48*45*36cm/13.4kg
Driver Windows XP /Vista/ Win7/Win8 /Win10/Win 2000/Win CE/OPOS/JPOS
SDK Android, IOS
Working
temperature&
humidity
0 to 45 degrees centigrade, 10%~80% No condensation
Storage
temperature&
humidity
-20 to 60 degrees centigrade , 10%~90% No condensation |
|
